MODEL |
SERIES 2800 |
Overall Size |
958(W) * 1,855(H) * 1,330 (L) mm |
Door Type |
Sliding Door |
Chamber |
Size |
450(W) * 500(H) * 1,250 (L) (Rectangular) |
Material |
Stainless Steel |
Capacity |
280Liter |
Jacket |
Material |
Stainless Steel |
Temperature Range |
110℃ ~ 135℃ (230℉∼275℉) |
Operation Cycle |
Pre-vacuum, Flash, Liquid, Gravity, Leak-Test, Bowie-Dick Test |
Printer |
Thermal Dot Matrix, 40 characters per line |
Control System |
Micro processor |
Dry System |
Vacuum with Watering Vacuum Pump (Standard) |
Water Ejector (Option) |
Electric consumption |
1P 220V and AC 380V, 50/60Hz, 22Kw |
Display |
Color 5.5” TFT-LCD Touch screen |
Steam Source |
Boiler Built In : 18 KW (380V 3P) Heater |
(Select) |
Pipe 1/2”, Flow rate - Max 75kg/hr, Pressure 3.5 ~ 5Kgf/cm2 |
Water supply |
1/2” above, Water pressure 1~3kgf/cm2 |
Air Supply |
1/4”, Air pressure 4 ~ 6Kgf/cm2 |
Drain pipe |
Copper or steel, above 1” |
Weight |
790 Kg |
Accessories |
Door gasket- Silicon, Printer Paper rolls, Air Bacteria Filters |
